In Winner you can use Offset/ Change position to adjust the position of objects in your plan. From update 12.3a3.0, in the Change position window, an additional offset option allows you to move the selected object by using the arrow keys on your keyboard. This feature is usable in both the Plan and Elevation window.
Using Offset in the Plan window
Take the following steps to use this new feature with the Plan window selected:
- In furnishing mode, click the object you want to adjust the position of.
-
Right-click and select Offset, or hit Ctrl + Shift + Y.
- With the Change position window open, you can now position the Cursor direction by hitting left or right on your keyboard. Once the direction is set, you can hit up or down to move in the direction set by the cursor.
The default distance is 100mm.
Use Shift and arrow keys to move 50mm.
Use Ctrl and arrow keys to more 10mm.
Use Shift, Ctrl and arrow keys to move 1mm.
Using Offset in the Elevation window
Take the following steps to use this new feature with the Elevation window selected:
- In furnishing mode, click the object you want to adjust the position of.
-
Right-click and select Offset, or hit Ctrl + Shift + Y.
- With the Change position window open, you can now position the Cursor direction by hitting any direction on your keyboard. As it is in Elevation mode, it will only move 2-dimensionally, but you can easily position objects to any height needed.
The default distance is 100mm.
Use Shift and arrow keys to move 50mm.
Use Ctrl and arrow keys to more 10mm.
Use Shift, Ctrl and arrow keys to move 1mm.
